Here's a program which does a clean "print" of the details of a Code Inspector variant. It generates an intermediate XML containing the variant tests and selected attributes, convert the XML into an ABAP internal table via a Simple Transformation Z_CI_XML_TO_ITAB, and the internal table is output as a text with indented hierarchy.
*&---------------------------------------------------------------------*
*& Report z_export_variante_ci
*&---------------------------------------------------------------------*
*&
*& https://community.sap.com/t5/application-development-and-automation-discussions/print-details-of-an-atc-code-inspector-check-variant-not-the-results/td-p/12804009
*&
*&---------------------------------------------------------------------*
REPORT z_export_variante_ci LINE-SIZE 1023.
CLASS lcl_app DEFINITION DEFERRED.
PARAMETERS variname TYPE sci_chkv OBLIGATORY DEFAULT 'ZCHECK_PROGRAM'.
SELECTION-SCREEN BEGIN OF SCREEN 1001.
PARAMETERS dummy.
SELECTION-SCREEN END OF SCREEN 1001.
AT SELECTION-SCREEN OUTPUT.
CASE sy-dynnr.
WHEN '1001'.
" Use of PBO to make warning SCI144 (CL_CI_TESTS=>GET_INITIAL_TREE) displayed
" as status message to not interrupt the logic (as done in SCI).
CALL METHOD lcl_app=>('CALCULATE_VARIANT_OUTPUT').
LEAVE TO SCREEN 0.
ENDCASE.
START-OF-SELECTION.
TRY.
CALL SELECTION-SCREEN 1001.
CALL METHOD lcl_app=>('RENDER_VARIANT_OUTPUT').
ASSERT 1 = 1. " dummy statement for setting a breakpoint (if debug needed)
CATCH cx_root INTO DATA(error).
MESSAGE error TYPE 'I' DISPLAY LIKE 'E'.
ENDTRY.
CLASS lcx_system_message DEFINITION INHERITING FROM cx_no_check FINAL.
PUBLIC SECTION.
METHODS constructor.
METHODS get_text REDEFINITION.
METHODS get_longtext REDEFINITION.
PRIVATE SECTION.
DATA text TYPE string.
ENDCLASS.
CLASS lcx_no_check DEFINITION INHERITING FROM cx_no_check FINAL.
PUBLIC SECTION.
METHODS constructor IMPORTING !text TYPE csequence.
METHODS get_text REDEFINITION.
METHODS get_longtext REDEFINITION.
PRIVATE SECTION.
DATA text TYPE string.
ENDCLASS.
CLASS lcl_app DEFINITION FINAL CREATE PRIVATE.
PUBLIC SECTION.
CLASS-METHODS calculate_variant_output.
CLASS-METHODS render_variant_output.
PRIVATE SECTION.
TYPES:
BEGIN OF ty_parameter,
value TYPE string,
description TYPE string,
END OF ty_parameter.
TYPES ty_parameters TYPE STANDARD TABLE OF ty_parameter WITH EMPTY KEY.
TYPES:
BEGIN OF ty_group,
description TYPE string,
parameters TYPE ty_parameters,
END OF ty_group.
TYPES ty_groups TYPE STANDARD TABLE OF ty_group WITH EMPTY KEY.
TYPES:
BEGIN OF ty_check,
check_class_name TYPE seoclsname,
has_attributes TYPE abap_bool,
parameters TYPE ty_parameters,
groups TYPE ty_groups,
END OF ty_check.
TYPES ty_checks TYPE STANDARD TABLE OF ty_check WITH EMPTY KEY.
CLASS-DATA checks TYPE lcl_app=>ty_checks.
CLASS-DATA tests TYPE sci_tabtest.
CLASS-DATA result TYPE string_table.
CLASS-METHODS export_category
IMPORTING category TYPE REF TO if_ci_test
RETURNING VALUE(result) TYPE string_table.
CLASS-METHODS get_variant_tree
RETURNING VALUE(r_hier) TYPE REF TO cl_ci_tests
RAISING cx_parameter_invalid_range
cx_parameter_invalid_type
cx_sy_codepage_converter_init
cx_sy_conversion_codepage.
ENDCLASS.
CLASS lcl_app IMPLEMENTATION.
METHOD calculate_variant_output.
DATA(tree) = get_variant_tree( ).
" Export the top test category. It's a recursive method to export the child categories.
result = export_category( tree->tree ).
ENDMETHOD.
METHOD render_variant_output.
LOOP AT result REFERENCE INTO DATA(line).
WRITE / line->*.
ENDLOOP.
ENDMETHOD.
METHOD get_variant_tree.
cl_ci_checkvariant=>get_ref( EXPORTING p_user = space " space for global variant
p_name = variname
RECEIVING p_ref = DATA(variant)
EXCEPTIONS chkv_not_exists = 1
missing_parameter = 2
broken_variant = 3
OTHERS = 4 ).
CASE sy-subrc.
WHEN 0. " ##NO_HANDLER.
WHEN 1.
RAISE EXCEPTION TYPE lcx_no_check
EXPORTING text = 'Variant does not exist'.
WHEN OTHERS.
RAISE EXCEPTION TYPE lcx_system_message.
ENDCASE.
DATA(config) = NEW cl_ci_variant_configuration( ).
DATA(xml) = config->variant_to_xml( variant = variant ).
" Needed for ADT 3.48 debugger because of" missing "Wrap Text" feature in XSTRING XML Viewer.
IF 0 = 1.
DATA(xml_2) = cl_abap_codepage=>convert_from( xml ) ##NEEDED.
ENDIF.
checks = VALUE ty_checks( ).
CALL TRANSFORMATION z_ci_xml_to_itab
SOURCE XML xml
RESULT checks = checks.
" GET INSTANCES OF ALL TEST CLASSES SELECTED IN THE VARIANT
variant->get_info( EXCEPTIONS could_not_read_variant = 1
OTHERS = 2 ).
IF sy-subrc <> 0.
RAISE EXCEPTION TYPE lcx_no_check
EXPORTING text = 'Error of IMPORT FROM DATABASE SCICHKV_PA(AR)'.
ENDIF.
" ADD MISSING TESTS (those with no attributes)
" This call is a complement of VARIANT_TO_XML which doesn't fill XML for tests without attributes.
" NB: GET_LIST works only if called after GET_INFO.
cl_ci_tests=>get_list( EXPORTING p_variant = variant->variant
RECEIVING p_result = DATA(collection_of_variant_tests)
EXCEPTIONS invalid_version = 1
OTHERS = 2 ).
IF sy-subrc <> 0.
RAISE EXCEPTION TYPE lcx_no_check
EXPORTING text = 'Version incorrecte du test dans la variante'.
ENDIF.
LOOP AT collection_of_variant_tests->give_list( ) INTO DATA(test)
WHERE table_line->has_attributes = abap_false.
INSERT VALUE #( check_class_name = test->name )
INTO TABLE checks.
ENDLOOP.
" NEED TO RUN GET_TREE INSIDE DYNPRO (dynpro 1001 here) BECAUSE IT RUNS MESSAGE W144 (otherwise that stops a non-background process).
cl_ci_tests=>get_tree( EXPORTING p_variant = variant->variant
p_transport = abap_false
RECEIVING p_result = r_hier
EXCEPTIONS invalid_category = 1
invalid_class_name = 2
OTHERS = 3 ).
IF sy-subrc <> 0.
RAISE EXCEPTION TYPE lcx_system_message.
ENDIF.
ENDMETHOD.
METHOD export_category.
LOOP AT category->childs INTO DATA(child_test_or_category_2).
IF child_test_or_category_2 IS INSTANCE OF cl_ci_category_root.
DATA(intermediate_result) = export_category( child_test_or_category_2 ).
INSERT LINES OF intermediate_result INTO TABLE result.
ELSE.
DATA(check) = REF #( checks[ check_class_name = child_test_or_category_2->name ] OPTIONAL ).
IF check IS NOT BOUND.
CONTINUE.
ENDIF.
INSERT |{ check->check_class_name } { child_test_or_category_2->description }| INTO TABLE result.
IF check->has_attributes = abap_false.
INSERT | No attribute| INTO TABLE result.
ELSE.
LOOP AT check->parameters REFERENCE INTO DATA(parameter).
INSERT | {
COND #( WHEN parameter->description IS NOT INITIAL
THEN parameter->description
ELSE '(no parameter description)' )
} : {
COND #( WHEN parameter->value IS NOT INITIAL
THEN parameter->value
ELSE '(no value or false)' )
} {
child_test_or_category_2->description }|
INTO TABLE result.
ENDLOOP.
LOOP AT check->groups REFERENCE INTO DATA(group).
INSERT | {
COND #( WHEN group->description IS NOT INITIAL
THEN group->description
ELSE '(no group description)' ) }|
INTO TABLE result.
LOOP AT group->parameters REFERENCE INTO parameter.
INSERT | {
COND #( WHEN parameter->description IS NOT INITIAL
THEN parameter->description
ELSE '(no parameter description)' )
} : {
COND #( WHEN parameter->value IS NOT INITIAL
THEN parameter->value
ELSE '(no value or false)' ) }|
INTO TABLE result.
ENDLOOP.
ENDLOOP.
ENDIF.
ENDIF.
ENDLOOP.
IF result IS NOT INITIAL.
LOOP AT result REFERENCE INTO DATA(result_line).
result_line->* = | { result_line->* }|.
ENDLOOP.
INSERT |{ category->name } { category->description }| INTO result INDEX 1.
ENDIF.
ENDMETHOD.
ENDCLASS.
CLASS lcx_system_message IMPLEMENTATION.
METHOD constructor.
super->constructor( textid = textid
previous = previous ).
MESSAGE ID sy-msgid TYPE sy-msgty NUMBER sy-msgno
WITH sy-msgv1 sy-msgv2 sy-msgv3 sy-msgv4 INTO text.
ENDMETHOD.
METHOD get_longtext.
result = text.
ENDMETHOD.
METHOD get_text.
result = text.
ENDMETHOD.
ENDCLASS.
CLASS lcx_no_check IMPLEMENTATION.
METHOD constructor.
super->constructor( textid = textid
previous = previous ).
me->text = text.
ENDMETHOD.
METHOD get_longtext.
result = text.
ENDMETHOD.
METHOD get_text.
result = text.
ENDMETHOD.
ENDCLASS.
Simple Transformation Z_CI_XML_TO_ITAB:
<!-- https://community.sap.com/t5/application-development-and-automation-discussions/print-details-of-an-atc-code-inspector-check-variant-not-the-results/td-p/12804009 -->
<?sap.transform simple?>
<tt:transform
xmlns:tt="http://www.sap.com/transformation-templates"
xmlns:ci="https://www.sap.com/adt/codeinspector/checkvariant">
<tt:root name="CHECKS"/>
<tt:template>
<ci:variant tt:extensible="deep-dynamic">
<tt:loop ref="CHECKS">
<check>
<tt:attribute name="technicalName" value-ref="CHECK_CLASS_NAME"/>
<tt:assign to-ref="HAS_ATTRIBUTES" val="'X'"/>
<tt:loop ref="PARAMETERS">
<parameter>
<tt:cond>
<tt:attribute name="value" value-ref="VALUE"/>
</tt:cond>
<tt:cond>
<tt:attribute name="description" value-ref="DESCRIPTION"/>
</tt:cond>
</parameter>
</tt:loop>
<tt:loop ref="GROUPS">
<group>
<tt:attribute name="description" value-ref="DESCRIPTION"/>
<tt:loop ref="PARAMETERS">
<parameter>
<tt:cond>
<tt:attribute name="value" value-ref="VALUE"/>
</tt:cond>
<tt:cond>
<tt:attribute name="description" value-ref="DESCRIPTION"/>
</tt:cond>
</parameter>
</tt:loop>
</group>
</tt:loop>
</check>
</tt:loop>
</ci:variant>
</tt:template>
</tt:transform>
Final result in an ABAP List (ABAP WRITE) / truncated to fit forum maximum:
CL_CI_CATEGORY_ABAP_COMPILER
CL_CI_TEST_ABAP_GENERATE Generate ABAP Programs
Generate only if necessary : false
CL_CI_TEST_EXPORT_COMP_PROCS_E Export of Program Information
Export Using RFC : false
RFC Destination : (no value or false)
With Call Level : 0
Force Generation : false
CL_CI_TEST_EXTENDED_CHECK Extended Program Check (SLIN)
(no parameter description) : 1
(no group description)
PERFORM/FORM Interfaces : true
CALL FUNCTION/METHOD Interfaces : true
CL_CI_TEST_SYNTAX_CHECK Syntax Check
More than one error : true
Warnings : true
Message Codes : (no value or false)
CL_CI_CATEGORY_SECURITY
CL_CI_TEST_CRITICAL_STATEMENTS Critical Statements
Calls
C-CALLs : true
SYSTEM-CALL : true
Database
ROLLBACK WORK : true
Dynamic Program Editing
GENERATE ... : true
READ REPORT : false
INSERT/DELETE REPORT : true
CL_CI_TEST_FIND_DYN_SQL Use of ADBC Interface
Find uses of ...
... ADBC classes : true
... other classes : (no value or false)
One message per ...
(no parameter description) : 1
CL_CI_TEST_SHO_CLIENT Client-Specific Shared Objects Methods
Attach Class Methods
ATTACH_FOR_READ : true
ATTACH_FOR_WRITE : true
ATTACH_FOR_UPDATE : true
Detach Class Methods
DETACH_AREA : true
DETACH_ALL_AREAS : true
CL_CI_CATEGORY_ROBUSTNESS
CL_CI_TEST_INT8 Test to check handling of type INT8
Analyze only local procedures : true
Non-local analysis depth : 1
(no group description)
Show detail information : false
Inverted check : false
